Making sense of VoIP systems: live or die on the network path

The phone system used to be a cabinet in a cupboard with wires to every desk. It is now a piece of software somewhere, a set of devices that talk to it, and the network in between. Two of those three are yours to look after, and the middle one is where nearly all the trouble lives.

What to take away

The three parts, and how each one fails

The endpoints. Desk phones, an app on a computer, an app on a mobile. A

The service. Either hosted by the provider, on a platform such as RingCentral, Zoom Phone or Microsoft Teams Phone, or a server on your premises running an IP PBX such as Asterisk or FreePBX. A failure here affects everyone at once, which is why the choice between the two is mostly about who you want to be responsible when it happens.

The path. Handset to switch, switch to your router, router to the connection, connection to the provider's network, and on to whoever you are calling. This is where poor quality comes from, and it is the part most contracts leave in your hands. The connection at the end of that chain is a decision of its own: fiber internet sends about as fast as it receives, which is the direction calls need.

Why a call sounds bad while the web works fine

A web page arrives whenever it arrives. A voice call has to arrive in order,

on time, continuously, in both directions. Three things break that:

None of these is measured by a speed test, and none improves when you buy a bigger connection. What does help:

If calls are fine in the morning and poor mid-afternoon, the path is congested at that hour and prioritization inside the building is the first thing to fix.

Hosted or on your premises

A hosted service puts the switch in the provider's hands. You get a web

A server on your premises keeps internal calls inside the building. You are in charge of everything else: patching, backups, power, and reachability from outside for remote staff. That brings a security job with it. Some businesses have the people for that. Most do not.

There is no wrong answer. There is a wrong reason: choosing the on-premises option to save money, then budgeting nobody's time to run it.

Three things to settle before you move

Three things decide whether a move goes quietly: what still rings when the power goes, whether the numbers can leave with you, and how emergency calls are handled. Settle all three in writing before you sign.

What still rings when the power goes

An internet-based phone needs power at the desk, power at the switch, power

Whether you can take your numbers with you

Moving numbers in is the sales conversation. Moving them out is the one to have before you sign. In the United States, the FCC's porting rules at 47 CFR 52.35 require a simple port — a number moving on its own, with the account details matching — to be finished within one business day of a valid request, while complex ports covering several numbers or services take longer. So ask which of your numbers would qualify as simple, what porting them away at the end of the term involves, and what it costs in the contract's own words. A provider who makes leaving hard is telling you something.

How emergency calls are handled

On a traditional line the address of a call was the address of the wire. On an internet-based service the phone can be anywhere, and the address the emergency service sees is whatever the provider holds for it. In the United States, the FCC's rules for interconnected VoIP sit in 47 CFR Part 9: the provider has to obtain a registered location for each line, pass it to the 911 network, and report significant outages under the FCC's disruption-reporting rules in 47 CFR Part 4. The FCC's consumer guide on VoIP and 911 sets out the practical concerns for customers.

Outside the United States, ask your national regulator what it requires for emergency call routing, address updates and outage reporting on internet-based phone services.

Whatever your country, confirm with the provider, in writing. Ask how emergency calls are routed on their service, what address is passed, and how it is updated when someone works from home or another site.

Ask what happens when the connection or power is down. Then tell your staff, because the honest answer in many setups is that a mobile is the better phone to reach for in an emergency.

Security is the fourth thing worth settling. NIST SP 800-58, Security Considerations for Voice Over IP Systems, is the federal reference for voice over IP systems. Voice on a data network inherits that network's problems and adds a billing relationship on top. The account that can place calls needs limits as well as a password.

Rolling it out

A port runs through the account record rather than the phone system. The account holder signs a letter of authorization (LOA) naming the numbers and the receiving provider, and business phone numbers sets out who has to authorize one. The order matters because porting is the slowest step and the hardest to reverse.

Doing it first, to save a month of paying twice, is how businesses end up with a number that rings a system that is not ready.

What to keep on file

Three records make every future problem shorter:

Common questions

Do I need a special connection for it?

Not a special one, a suitable one. Stable, with adequate upload, low variation and a router that can prioritize. A second connection that fails independently, such as fixed wireless, matters more for phones than for almost anything else because a phone outage is visible to customers immediately.

Can staff use their own mobiles?

Usually, through an app that presents the business number. The number they show when calling out and the number the business keeps when they leave are the two things to configure and check.

How many simultaneous calls can I make?

That is set by your plan and by the path. As a typical figure, a call uses roughly 100 kbps in each direction once codec overhead is counted. Ask the provider for their per-call network requirement and hold it against the upload capacity you actually measured at the busy hour.

What if the provider goes out of business?

Your numbers are the exposure. Keep the account holder details correct and a current export of your routing configuration so it can be rebuilt elsewhere.
